Magic Mobility Frontier V6 - Tyres, Castors, and Punctures

Form 07A –Frontier V6, V4 and Extreme X8 Owner’s Manual ENGLISH.docx Revision No.4
© Magic Mobility Page 49 of 65
Tyre pressures should be checked weekly. All pneumatic tyres are fitted with automotive type valves
and can be inflated using most typical automotive hand and foot type pumps as well as service
station air outlets.
STOP! Under inflated tyres may be dangerous and can leave the tyres prone to
punctures. Failure to use the correct inflation pressure can result in reduced
performance or cause an unsafe situation to occur
STOP! Over inflated tyres may cause the tyre to explode and cause bodily harm.
The recommended tyre pressure is also listed on the sidewall of the tyre
9.3.1 Frontier Tyre Inflation
Tyre Description
Magic Mobility
Recommended
Optimum
Operating Pressure
Maximum Tyre
Pressure according to
tyre capacity
All-terrain
Black, Low Pressure,
Knobby
3.6 psi (25 kPa)
MAX 8psi (55kPa)
24 psi
165 kPa
Hybrid
14 x 3
Pneumatic
36 psi (248kPa)
50 psi
343 kPa
Compact 73 and 40
12 ½ x 2 ¼
pneumatic
36 psi (248kPa)
40 psi
275 kPa
Castors (Compact)
200x50 or 175x50
Pneumatic
36 psi (248kPa)
36 psi
248 kPa
Castors
(AT and Hybrid)
2.50-4
Pneumatic
36 psi (248kPa)
36 psi
248 kPa
9.3.2 Extreme X8 Tyre inflation
Tyre
Tyre Description
Magic Mobility
Recommended
Optimum
Operating Pressure
Maximum Tyre
Pressure according
to tyre capacity
All Tyres
Black, Low Pressure, Knobby
3.6 psi (25 kPa)
MAX 8psi (55kPa)
24 psi
165 kPa
Advisory Tyre Pressures for user weight (Metric)
0
10
20
30
40
50
60
68 91 114 136 159 182
Tyre Pressure (kPa)
User Weight (kg)
