41
48-640 E3 Modulevel
®
Displacer Level Transmitter - FOUNDATION fieldbus
™
The following table lists the conditions indicated in the
Device Status parameter. It also shows the affect the condition
has on PV status, Sub-Status and Limit, XD ERROR and
BLOCK ALARM are not affected by these conditions directly.
The first three conditions are Type Mode. If everything is
running normally and there are no Faults or Warnings, then
the device indicates it is “OK” an the local display and in
Device Status viewed from the F
OUNDATION fieldbus
™
net-
work. If a password is entered through the local display, the
Transducer Block is taken Out of Service if it is not already
and the User Access or Factory Access will be indicated in
Device Status viewed from the F
OUNDATION fieldbus. This
will indicate to the operator that an attempt is being made
to modify a parameter value. No indication is given on the
Fieldbus network if someone is only viewing parameters on
the local display.
The next set of conditions is device faults. The device will
most likely not be able to measure level correctly if one or
more of these conditions occur. The condition will be indi-
cated in Device Status and will affect PV Status, Sub-Status
and Limit as indicated.
Mode OK 11 0x0800 Good Non-Specific Not Limited
Mode User Access 2 0x0004 Bad OOS Not Limited
Mode Factory Access 14 0x4000 Bad OOS Not Limited
Faults Default Params 12 0x1000 Bad Configuration Error Not Limited
Faults Primary Fault 9 0x0200 Bad Device Failure Constant Limited
Faults Core Drop 8 0x0100 Bad Sensor Failure Low Limited
Faults SecFaultHi 10 0x0400 Bad Sensor Failure High Limited
Faults
SecFaultLo ¿
13 0x2000 Bad Sensor Failure Low Limited
Warning Default Cal 5 0x0020 No Effect No Effect No Effect
Warning Hi Temperature 4 0x0010 No Effect No Effect No Effect
Warning Lo Temperature 3 0x0008 No Effect No Effect No Effect
Warning Cal Span 6 0x0040 No Effect No Effect No Effect
Warning Initializing 1 0x0002 Uncertain Initial Value Constant Limited
Faults Fault 1 15 0x8000 No Effect No Effect No Effect
Warning Warning 2 0 0x0001 No Effect No Effect No Effect
Warning Warning 1 7 0x0080 No Effect No Effect No Effect
¿
This fault disabled with interface
or density measurement.
