Magnetrol E3A - Fieldbus Configuration Data Sheet

48-640 E3 Modulevel
®
Displacer Level Transmitter - FOUNDATION fieldbus
™
59
E3 Modulevel
®
Displacer Level Transmitter
FOUNDATION fieldbus
™
Configuration Data Sheet
Copy blank page and store calibration data for future reference and troubleshooting.
Item Value Value Value
TROUBLESHOOTING
Working Value Non-Working Value
Vessel Name
Vessel #
Process Medium
Tag #
Serial #
Model #
Meas Type
Level Units
Process SG
Process Temperature
Level Offset
LVDT Damping
Trim Level
Spring SG
Spring Rate
Spring Material
Temperature Limit
Displacer Length
Displacer Diameter
Displacer Weight
CalSelect
Conv Fct
Scl Ofst
Calib SG
DrySensr
SnrCalLo
LvlCalLo (or SGCalLo)
SnrCalHi
LvlCalHi (orSGCalHi)
Name
Date
Time
