Magnetrol E3A - Atex; Explosion Protection)

45
48-640 E3 Modulevel
®
Displacer Level Transmitter - FOUNDATION fieldbus
™
 

 




   
 ATEX Ex II 1/2 G Ex d IIC T6
 EN 60079-0, EN 60079-1,
 EN 60079-26
 94/9/EC


  ➂
 ATEX Ex II 1 G Ex ia IIC T4
 EN 60079-0, EN 60079-11,
 EN 60079-26, EN 60079-27
 94/9/EC


  
 ATEX Ex II 3 G Ex ic II T6
 EN 60079-0
 EN 60079-11
 94/9/EC


   
 IECEx Ex d IIC T6 Ga/Gb
 IEC 60079-0
IEC 60079-1
IEC 60079-26
  ➂
 IECEx Ex ia IIC T4 Ga
 IEC 60079-0
IEC 60079-11
IEC 60079-26
IEC 60079-27
These units have been tested to
EN 61326 and are in compliance with
the EMC Directive 2004/108/EC.
¿ On remote electronics housing only, seal is required within 18
inches.
¡ Entity parameters for intrinsically safe installation (FM & CSA):
non-FISCO
V
max
= 28.6 V
I
max
= 140 mA
P
max
= 1 W
C
i
= 5.5 nF
L
i
= 9.4 µH
for FISCO Intrinsically Safe
V
max
= 17.5 V
I
max
= 500 mA
P
max
= 5.5 W
C
i
≤ 5 nF
L
i
≤ 10 µH
➂ Entity parameters for intrinsically safe installation (ATEX/IEC):
non-FISCO
U
i
= 28.4 V
I
max
= 94 mA
P
max
= 0.67 W
C
i
= 2.2 nF
L
i
= 3 µH
for FISCO Intrinsically Safe
U
i
= 17.5 V
I
max
= 380 mA
P
max
= 5.32 W
C
i
= 0.705 nF
L
i
= 3 µH
