Magnetrol E3A - References; Ppendix - Transducer Block Parameters

58
48-640 E3 Modulevel
®
Displacer Level Transmitter - FOUNDATION fieldbus
™
Appendix – Transducer Block Parameters
8.8 References
1. F
OUNDATION fieldbus
™
, A Pocket Guide
Ian Verhappen, Augusto Pereira
2. F
OUNDATION fieldbus
™
—System Engineering Guidelines, AG–181
  
0 BLOCK_STRUCTURE BLOCK STRUCT
1 ST_REV ST REV
2 T
AG_DESC
T
AG DESC
3 STRATEGY STRATEGY
4 ALERT_KEY ALERT KEY
5 MODE_BLK MODE BLK
6 BLOCK_ERR BLOCK ERR
7 UPDATE_EVT UPDATE EVT
8 BLOCK_ALM BLOCK ALM
9 TRANSDUCER_DIRECTORY XD DIRECTORY
10 TRANSDUCER_TYPE XD TYPE
11 XD_ERROR XD ERROR
12 COLLECTION_DIRECTORY COLLECT DIR
13 MEASUREMENT_TYPE Measurement Type
14 PRIMARY_VALUE Primary Value
15 PRIMARY_VALUE_UNIT Primary Value Unit
16 LVDT_DAMPING LVDT Damping
17 PROCESS_SG Process SG
18 PROCESS_TEMPERTURE Process Temperature
19 LEVEL_OFFSET Level Offset
20 TRIM_LEVEL Trim Level
21 MODEL_NUMBER Model Number
22 LEVEL_UNIT Level Unit
23 DISPLACER_LENGTH Displacer Length
24 DIAMETER_UNIT Diameter Unit
25 DISPLACER_DIAMETER Displacer Diameter
26 WEIGHT_UNIT Weight Unit
27 DISPLACER_WEIGHT Displacer Weight
28 SPRING_SG Spring SG
29 SPRING_RATE Spring Rate
30 SPRING_MATERIAL Spring Material
31 PROCESS_TEMP_LIMIT Process Temp Limit
32 LOWER_SG Lower SG
33 UPPER_SG Upper SG
34 SPECIFIC_GRAVITY_UNIT SG Unit
35 TRIM_SG Trim SG
36 ENTER_PASSWORD Enter Password
37 NEW_PASSWORD New User Password
38 DEVICE_STATUS Device Status
39 HISTORY_STATUS History Message
  
40 HISTORY_CONTROL History Control
41 RESET_HISTORY Reset History
4
2
C
ALIBRATION_SELECT
C
alibration Select
43 LVDT_OUTPUT LVDT%
44 SENSOR_UNIT Sensor Unit
45 FACTORY_CALIBRATION_SG Factory Calibration SG
46 FACTORY_DRY_SENSOR Factory Dry Sensor
47 FACTORY_SENSOR_CAL_LO Factory Sensor Cal Lo
48 FACTROY_SENSOR_CAL_HI Factory Sensor Cal Hi
49 FACTORY_LEVEL_CAL_LO Factory Level Cal Lo
50 FACTORY_LEVEL_CAL_HI Factory Level Cal Hi
51 FACTORY_SG_CAL_LO Factory SG Cal Lo
52 FACTORY_SG_CAL_HI Factory SG Cal Hi
53 USER_DRY_SENSOR User Dry Sensor
54 USER_SENSOR_CAL_LO User Sensor Cal Lo
55 USER_SENSOR_CAL_HI User Sensor Cal Hi
56 USER_LEVEL_CAL_LO User Sensor Cal Lo
57 USER_LEVEL_CAL_HI User Level Cal Hi
58 USER_SG_CAL_LO User SG Cal Lo
59 USER_SG_CAL_HI User SG Cal Hi
60 ADJUSTED_SENSOR_LO Adjusted Sensor Lo
61 ADJUSTED_SENSOR_HI Adjusted Sensor Hi
62 CONVERSION_FACTOR Conversion Factor
63 SCALE_OFFSET Scale Offset
64 LVDT_CHANNEL_0 LVDT Channel 0
65 LVDT_CHANNEL_1 LVDT Channel 1
66 TEMPERATURE_UNIT Temperature Unit
67 ELECTRONICS_TEMPERATURE Elec Temperature
68
MAX_ELECTRONICS_TEMPERATURE Max Temperature
69
MIN_ELECTRONICS_TEMPERATURE Min Temperature
70
RESET_ELECTRONICS_TEMPERATURE Reset Temperatures
71 LCD_LANGUAGE LCD Language
72 NSP_VALUE NSP Value
73 FACTORY_PARAM_1 Factory Param 1
74 FACTORY_PARAM_2 Factory Param 2
75 NON_VOL_STAT Non Vol Stat
76 DATE_CODE Date Code
77 MAGNETROL_SERIAL_NUMBER MAGNETROL S/N
78 FIRMWARE_VERSION Firmware Version
