50
8.6 Specifications
48-640 E3 Modulevel
®
Displacer Level Transmitter - FOUNDATION fieldbus
™
Measurement Principle Buoyancy – continuous displacement utilizing a precision range spring
Measured Variable Level, determined by LVDT core movement affected by
buoyancy force changes on continuous displacer
P
hysical Range Up to 120" (300 cm) based on displacer length (C/F for longer ranges)
Keypad 3-button menu-driven data entry and system security
Indication 2-line × 8-character LCD display
Digital Communication F
OUNDATION fieldbus
™
, H1 (31.25 kbits/sec)
Interoperability test kit (ITK Revision) ITK 5.0, LAS capable
LAS capable Yes, Device type: Basic
DEV Revision 0X01
Available Blocks AI, PID, RB, TB
Polarity Sensitive No
Damping Adjustable 0-45 seconds
Block Execution Time 15 msec
(Measured at instrument terminals)
Fieldbus General Purpose/Explosion Proof 9 to 32 VDC (17 mA maximum current draw)
This device provides only Functional Isolation
IS/FISCO/FNICO 9 to 32 VDC (17 mA maximum current draw)
This device provides only Functional Isolation
Material Aluminum A356T6 (<0.20% copper), optional 316 stainless steel
Cable Entry
3
⁄4" NPT and M20
Ingress Protection TYPE 4X, IP66
Materials Carbon steel
316/316L stainless steel
Wetted parts 316/316L and Inconel
®
(spring)
Process connections Tank Top: 3", 4", 6" ANSI Flange
Chambered: 1
1
⁄2", 2" NPT
1
1
⁄2", 2" Socketweld
1
1
⁄2", 2" ANSI Flanges
