4.5 Model 706 Configuration Menu — Device Setup
L
evel Units:
I
nches
F
e
et
Millimeters
C
entimeters
M
eters
D
istance Units:
Inches
F
eet
Millimeters
C
entimeters
M
e
ters
I
nterface Level Units:
Inches
Feet
M
illimeters
Centimeters
M
eters
Upper Thickness Units:
I
nches
Feet
Millimeters
Centimeters
Meters
Temperature Units:
Celcius
Fahrenheit
P
robe Model:
7
YD Coax HTHP
7YF Sngl Rod Tanks
7
YG Sngl Rod Cages
7YJ Sngl Rod HTHP Cages
7
YL Sngl Rod HPCages
7
YM Sngl Rod HP Tanks
7YN Sngl Rod HTHP Tanks
7
Y
PCoaxHP
7
YS Coax Steam
7
YT Coax Std
7Y1 Sngl Flex Std
7
Y
2SnglFlexBulk
7
Y3 Sngl Flex HP
7
Y5 Twin Flex Bulk
7Y6 Sngl Flx HTHP Cage
7Y7 Twin Flex Clad
P
robe Coating: (7yF only)
None (Bare)
PFA Coated
Probe Mount:
NPT
BSP
F
lange
NPT/Flushing
BSP/Flushing
Flange/Flushing
Hygienic
Probe Length:
12 inches to 100 feet
(30 cmto30m)
Level Offset:
-25 feet to +75 feet
(-7.6 m to 22.9 m)
Dielectric Range:
Below 1.7
1.7 to 3.0
3.0 to10
Above 10
Upr Dielectric:
1.2 to10
Home Screen
Main Menu
D
evice Setup
Q
uick Start
Identity
B
a
sic Config
D
i
splay Config
A
dvanced Config
F
actory Config
M
easurement Type:
Level Only
I
n
terface and Level
I
n
terface and Volume
S
ystem Units
Volume and Level
F
low
Home Screen
Main Menu
Device Setup
Quick Start
Identity
Basic Config
I/O Config
Display Config
Advanced Config
Factory Config
Measurement Type:
Level Only
Interface and Level
Interface and Volume
Volume and Level
System Units
Flow
Probe Model:
7YD Coax HTHP
7YF Sngl Rod Std
7YG Sngl Rod Std
7YJ Sngl Rod HTHP Cages
7YL Sngl Rod HP Cages
7YM Sngl Rod HP Tanks
7YN Sngl Rod HTHP Tanks
7YP Coax HP
7YS Coax Steam
7YT Coax Std
7Y1 Sngl Flex Std
7Y2 Sngl Flex Bulk
7Y3 Sngl Flex HP
7Y5 Twin Flex Bulk
7Y6 Sngl Flx HTHP Cage
7Y7 Twin Flex Clad
Probe Coating: (7yF only)
None (Bare)
PFACoated
Probe Mount:
NPT
BSP
Flange
NPT/Flushing
BSP/Flushing
Flange/Flushing
Hygienic
Probe Length:
12 inches to 100 feet
(30 cm to30m)
Level Offset:
-25 feet to +75 feet
(-7.6 m to 22.9 m)
Dielectric Range:
Below 1.7
1.7 to3.0
3.0 to10
Above 10
Volume Setup:
Volume Units:
Cubic Feet
Cubic Inches
Gallons
Milliliters
Liters
Vessel Type:
Rectangular
Horizontal/Flat
Horizontal/Ellipse
Horizontal/Spherical
Spherical
Vertical/Flat
Vertical/Ellipse
Vertical/Spherical
Vertical/Conical
Custom Table
Vessel Dimensions:
(not used with Custom Table)
Radius
Ellipse Depth
Conical Height
Width
Length
Custom Table Setup:
Custom Table Type:
Linear
Spline
Level Input Source:
Keypad
Sensor
CUSTOM TABLE VALUES:
Up to 30 Pairs of
Level/Volume Data
Level Units:
Inches
Feet
Millimeters
Centimeters
Meters
Distance Units:
Inches
Feet
Millimeters
Centimeters
Meters
Temperature Units:
Celsius
Fahrenheit
Cubic Meters
Barrels
