BE57-646 ECLIPSE Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
    
No Echoes
A
ll PVs except
Elec Temperature
Bad Sensor Failure Constant limited
Lvl Below ProbeEnd
All PVs except
E
lec Temperature
Bad Sensor Failure Constant limited
EoP Below ProbeEnd
All PVs except
Elec Temperature
Bad Sensor Failure Constant limited
Software Error All PVs Bad Device Failure Constant limited
RAM Error All PVs Bad Device Failure Constant limited
ADC Failure All PVs Bad Device Failure Constant limited
EEPROM Error All PVs Bad Device Failure Constant limited
No Fiducial
All PVs except
Elec Temperature
Bad Device Failure Constant limited
Echo Lost
All PVs except
Elec Temperature
Bad Device Failure Constant limited
Inferred Level
Echo Strength
Ifc Level
Upper Thickness
Ifc Echo Strength
Probe Buildup
Bad Device Failure Constant limited
Totalizer Data Lost
NR Totalizer
R Totalizer
Bad Config Error Not limited
Default Parameters All PVs Bad Config Error Not limited
EoP Above ProbeEnd
All PVs except Elec
Temperature
Bad Config Error Not limited
Buildup Detection
disabled
Probe Buildup Bad Config Error Constant limited
MeasType !=
Interface & Level
Ifc Level
Upper Thickness
Ifc Echo Strength
Bad Config Error Constant limited
MeasType !=
Volume & Level
Volume Bad Config Error Constant limited
MeasType != Flow
Flow
Head
NR Totalizer
R Totalizer
Bad Config Error Constant limited
MeasType = Flow and
R Totalizer Mode off
R Totalizer Bad Config Error Constant limited
High Volume Alarm Volume Bad Config Error High limited
High Flow Alarm
Flow
Head
Bad Non-Specific High limited
Safety Zone Alarm
Level
Ifc Level
Upper Thick
Distance
Volume
Head
Flow
Bad Non-Specific Not limited
