BE57-646 ECLIPSE Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
    
Initializing
A
ll PVs except
Elec Temperature
Uncertain Initial Value Constant limited
D
ry Probe
Distance Good Non-Specific High limited
Level
I
fc Level
Upper Thickness
Volume
Flow
Head
Good Non-Specific Low limited
NR Totalizer
R Totalizer
Good Non-Specific Constant limited
TB Config Changed All PVs Good Non-Specific Not limited
Ramp Interval Error All PVs Good Non-Specific Not limited
High Elec Temp All PVs Good Non-Specific Not limited
Low Elec Temp All PVs Good Non-Specific Not limited
Calibration Req’d All PVs Good Non-Specific Not limited
Echo Reject Invalid All PVs Good Non-Specific Not limited
No Probe Target All PVs Good Non-Specific Not limited
Low Echo Strength All PVs Good Non-Specific Not limited
Low Ifc Echo Strength All PVs Good Non-Specific Not limited
Sequence Record All PVs Good Non-Specific Not limited
