3.1. Meter Description
1-Current Clamp
2-Non-Contact AC Voltage Indicator Light
3-Clamp Trigger
4-Relative/INRUSH/ESC Button
5-LCD Display
6-MODE/VFD Button
7-RANGE Button
3. Description
8-MENU Button
9-Rotary Function Swith
10-Data Hold/Flashlight Button
11-Battery Cover
12-COM Input Jack
13-VΩHz% CAP TEMP Jack
14-Flashlight
