CHALLENGERSERIES10‐60KVA  PRODUCTDESCRIPTION

AG–SD‐35Rev.No:1Rev.Date:25.09.2013PublicationNo:2 17


2.2.2Battery(stored)Mode
UPSrunsonbatterymodewhenthemainsvoltageisbad.BatteryVoltageisboostedforthe
sufficientDcbusvoltage.InordertoprovideproperDCBusvlotage,batteryvoltagewillbe
boosted.

2.2.3BypassMode
Inanoverloadcondition,orifthereisaproblemwiththedoubleconversion,theloadsare
fedbythebypassline.

UPSswitchestoACsupplyfrominverterforthatbystaticswitches.Invertermustbe
synchronizedwiththemainssupplyforthesetransitionstobeseamless.Thistransitions
mighttake15msdependingonthetypeofloadifinverteroutputisnotsynchronizedwith
themains.

2.2.4AutoRestartMode
UPSsuppliesitscriticalloadsuptoendofdischargevoltagelevelduetoanymainsfailure.
UPSfeedscriticalloadsuntillendofbatterydischargevoltagelevelcausedbyanymains
failure.Upswilloperateuntilbatterieschargingprocesscompletingafterthatwillbe
switchedoff.UPScanoperatebyitselfinspecifiedtimeaftermainsturnedbacktonormal
mode.Inthiscase,UPSkeepsoperatingproperaslongasUPSvoltagebeinginaccordance
criterias.ForChallengerSeriesUPS,thisfeatureisnotactivatedasfactoryinitialsetups.
