CHALLENGERSERIES10‐60KVA  EXPLANATIONSOFLOGGING
AG–SD‐35Rev.No:1Rev.Date:25.09.2013PublicationNo:2 60


5.ExplanationsofLogging
UPSwillbeepwhenanyproblemisdetected.Youcanseethefirstinformationaboutthe
situationonthefrontmonitorpanel.Thismaynotbeenoughmostofthetime.Inthiscase,you
canseethefollowingwarningsbyusinglogscreen.

Warning WarningDescription
1 RS232StartCommand UPSwasstartedbyRS232communicationsoftware.
2 RS232StopCommand  UPSwasstoppedbyRS232communicationsoftware.
3 AutoRestart
Afterthebatteriesdischargetotally,UPSrestarteditself
automaticallyafterthemeantimewhichadjustedthat
4 UPSStartup ThemainboardoftheUPSisenergized.
5 SoftStartFail UPScouldnotramptheDCbusup.
6 QuickBatteryTest Quickbatterytesthasbegan.
7 DeepBatteryTest Batterycapacitytesthasbegan.
8 BatterySelfTest Periodicalbatterytesthasbegan.
9 EndOfDischarge
Batteries’voltagehasgonebelowcutoffvoltagevaluewhile
UPSwasoperatingonthebatterymode.
10 OverloadTimeout
UPShasoperatedatoverloadmorethantimelimitadjusted.
TheLoadswillbetransferredtobypassline.
11 EndofBatteryTest
Batterytesthascompleted.Youcanseetheallresultsvia
frontpanelstatusmenu.
12 Batt.TestAborted
TestwasabortedmanuallyorbyUPSsincethecriterias
were not provided during battery test.
13 ManuelSwitchToBYP
Staticswitchsdirectionswerechangedmanuallytothe
bypasslineviaUPScommandmenu.
14 NoBattery Nobatterydetected.
