CHALLENGERSERIES10‐60KVA  PRODUCTDESCRIPTION

AG–SD‐35Rev.No:1Rev.Date:25.09.2013PublicationNo:2 20


2.4UserPanel
Userpanelconsistsofmimicdiagram,LCDscreen,EPObuttonandmenukeys.TheUPScanbe
controlledviathispanel.













CH1060EN05R0


1
RectifierindicatorLED
FlasheswhiletheDCbusisrampingup.IlluminateswhenRectifierworks.
2 AC/DCmodule(Rectifier)
3
BoostmodeindicatorLED
Illuminatesinbatterymode.FlasheswhenUPSisstartedupthroughbatteries.
4
BatterychargeindicatorLED
Illuminateswhilethebatteriesarecharging.
5 Batterymodule
6 DC/ACmodule(Inverter)
7
MainsbypassindicatorLED
Illuminateswhiletheloadsarefedthroughbypassline.
