4. Makesurethatthebatteriesareconnectedproperlyinseriesandparallel.
5. Connect the negative battery terminal to –BAT cable, also connect the positive battery
terminaltothe+BATcableintheUPS.
6. Checkthepolarityofthebatteryconnectiononceagain.
7. ReplacethebatteryfuseontheUPS.
CH1060EN22R0
8. Replacethebatteryfuseinthebatterycabinet.
9. Ifanyswitchbreakerexistonthebatterycabinet,switchONthem.
10. Pleasecheckthatwhetherthereisappropriatebatteryvoltageontheinputterminalsof
thebatteryofUPSbymeasurementtool.
Theexternalbatterycableselectionisdeterminedbytheapplication.Recommendedfuses
aregivenforUPSandbatterycabinet.Thelowestdiametercablethatcanbeconnectedto
thosefusesisrecommendedtobeused.Please,refertostandardcalledEN50525‐2‐31(VDE
0100‐430) in this subject. Bu konuda EN 50525‐2‐31(VDE 0100‐430) adlı standardı
referansalınız.selectionshouldbesuchthatthecablewillallowatmost0.5Vdcdecreasing.
“External Battery Temperature Measurement Kit” which is sold as optional is
recommended to purchase for optimization according to battery temperatures on the
external battery cabinets applications. Otherwise, your batteries will not be optimized
accordingtotemperatures.
