CHALLENGERSERIES10‐60KVA  EXPLANATIONSOFLOGGING
AG–SD‐35Rev.No:1Rev.Date:25.09.2013PublicationNo:2 63


47 UPSThyr.L2ShortC.
UPShasdetectedshortcircuitatinverterL2thyristor.UPS
willshutdown.
48 UPSThyr.L3ShortC.
UPShasdetectedshortcircuitatinverterL3thyristor.UPS
willshutdown.
49 UPSThyr.L1OpenC.
UPShasdetectedthatinverterL1thyristorcannotbe
activated.Loadwillbetransferredtobypassline.
50 UPSThyr.L2OpenC.
UPShasdetectedthatinverterL2thyristorcannotbe
activated.Loadwillbetransferredtobypassline.
51 UPSThyr.L3OpenC.
UPShasdetectedthatinverterL3thyristorcannotbe
activated.Loadwillbetransferredtobypassline.
52 BYPThyr.L1OpenC.
UPShasdetectedthatbypassL1thyristorcannotbe
activated.Loadwillbetransferredtoinverterline.
53 BYPThyr.L2OpenC.
UPShasdetectedthatbypassL2thyristorcannotbe
activated.Loadwillbetransferredtoinverterline.
54 BYPThyr.L3OpenC.
UPShasdetectedthatbypassL3thyristorcannotbe
activated.Loadwillbetransferredtoinverterline.
55 Parl.Phs.Rot.Err.
OneormoreofUPSswhichoperateinparalelmodedonot
matchinphasesequence.
56 BatteryStart StartingthroughbatterycommandhasbeengiventoUPS.
57 Parl.StartError
OneormoreofUPSswhichoperateinparalelmodecould
notstarttooperate.
58 InverterFault UPScouldn'tpreparetheinvertervoltage.
59 OutputOff
Statictransferswitchesalldisabled.Theloadscannotbe
energized.
60 NormalMode
UPSisoperatinginthenormalmode,loadareenergized
throughrectifier–inverterline.
61 BatteryMode
UPSisoperatinginthebatterymode,loadareenergized
throughbattery–inverterline.
62 BypassMode
UPSisoperatinginthebypassmode,loadareenergized
throughbypassline.
63 MaintenanceBypassMode
UPSisoperatinginthebypassmode,loadareenergized
throughbypassline.
