MAKELSAN LEVELUPS Series - Technical Specifications Summary

6 Table of Technical Specifications
Technical Specifications
Power
10kVA
15kVA
20kVA
Active Power
10Kw
15kW
20kW
Input
Input Voltage Range
220/380 VAC - %15 + %18 3P + N + PE
Input Power Factor
At Full Load > 0,99
Input Frequency Range
45-65 Hz (Selectable)
Rectifier
IGBT Rectifier
Total Harmonic Distortion
(THDi)
<%4
Output
Output Voltage Range
220/380 VAC 3P + N ± 1% Static, ± 1% Dynamic
Recovery
At 0% - 100% - 0% load, maximum output tolerance %5, %1 Back
to band <40ms.
Efficiency
Up to %96
Output Frequency Range
50Hz ±0,5% synchronous with the network, 50Hz ±
0,2% Battery Mode
Output THD (THDv)
Lineer Load <%2
Non-Lineer Load <%6
Crest Factor (CF)
3:1
Overload Capacity
At %125 load 10 min. , at %150 load 1 min.
Protections
The input voltage is out of tolerance, input frequency is out of
tolerance, input phase failure, output voltage is out of tolerance,
output frequency is out of tolerance, output phase failure, DC
component that can occur at the output voltage, Overload that will
occur at the output (out of the periods specified), Overheating that
will cause failure related to over temperature, high voltage which
will occur at DC Bus voltage, low voltage which will occur at DC
Bus voltage, short circuit at the output.
