LEVELUPS SERIES 10-20 KVA EXPLANATIONS OF LOGGING
AG-SD-83 / Publication Date: 15.09.2014 / Rev. No: 0 / Rev. Date:
5 EXPLANATIONS of LOGGING
UPS will beep when any problem is detected. You can see the first information about the
situation on the front monitor panel. This may not be enough most of the time. In this case, you
can see the following warnings by using log screen.
Event
Explanations
1
RS232 Start
Command
UPS was started by RS232 communication software.
2
RS232 Stop
Command
UPS was stopped by RS232 communication software.
3
Auto Restart
After the batteries discharge totally, UPS restarted itself automatically after the
mean time which adjusted that follows the mains getting back to normal
values.
4
UPS Startup
The main board of the UPS is energized.
5
Soft Start Fail
UPS could not ramp the DC bus up.
6
Quick Battery Test
Quick battery test has began.
7
Deep Battery Test
Battery capacity test has began.
8
Battery Self Test
Periodical battery test has began.
9
End Of Discharge
Batteries’ voltage has gone below cut off voltage value while UPS was
operating on the battery mode.
10
Overload Timeout
UPS has operated at overload more than time limit adjusted.The Loads will be
transferred to bypass line.
11
End of Battery Test
Battery test has completed.You can see the all results via front panel status
menu..
12
Batt. Test Aborted
Test was aborted manually or by UPS since the criterias were not provided
during battery test.
13
Manuel Switch To
BYP
Static switchs directions were changed manually to the bypass line via UPS
command menu.
14
No Battery
No battery detected.
15
Maint. BYP. Sw. On
Maintenance bypass switch has been activated.
16
Ambient Abnor.
Temp.
The ambient temperature is over limit. Check the ventilation of UPS room.
17
Inverter Overtemp.
Inverter's temperature is out of limit, in case of 5 degrees more increment
,Load will be transferred to Bypass line.
18
PFC Overtemp.
Rectifier 's temperature is out of limit, in case of 5 degrees more increment
,Load will be transferred to Bypass line.
19
STS Overtemp.
Static Transfer Switches’ temperatures are out of limits.UPS will be stopped.
20
Outp.PL1 Cur.
Limit.
Short circuit protection is activated for output L1 phase.
21
Outp.PL2 Cur.
Limit.
Short circuit protection is activated for output L2 phase.
22
Outp.PL3 Cur.
Limit.
Short circuit protection is activated for output L3 phase.
