Introduction
This chapter is designed to enable you to identify the physical features of the
Accessory and is divided into two parts.
The first part identifies the features of the Dispersion Unit & Controller Unit, for
example the function controls, connectors and indicators etc. The second part
identifies the areas of the Malvern software, which are pertinent to the Accessory.
Features of the Accessory
The illustration below identifies the main features of the Accessory.
Dispersion Unit Controller
INSTRUMENTS
Dispersion Unit Controller
INSTRUMENTS
RPM
Stirrer Speed
Small Volume Sample Dispersion Unit
INSTRUMENTS
Small Volume Sample Dispersion Unit
INSTRUMENTS
2
4
1
7
3
5
8
9
6
10
ILL 3045
CHAPTER 4
QS SMALL VOLUME SAMPLE DISPERSION UNIT Page 4.1
