À Dispersion Unit.
Á Tank cover.
 One metre of sample tubing (Inner diameter 3/16", external diameter 5/16")
à Two metres of braided PVC drain tubing (Inner diameter 5/8", external
diameter 7/8").
Ä Flow cell (Mastersizer S and X only, dependent on your order).
Å Window tool (dependent on your order).
Æ Small volume cell top (Mastersizer Micro and Microplus only, dependent on
your order).
Ç Controller Unit.
È Software (Qspec MS1 macro) installation disk.
É Mains power cable.
5
37 way cable. (digital I/O connector) - Mastersizer X/S only.
Connecting up your Accessory
Mastersizer S and X
(
Note:
.
It is assumed your Dispersion Unit is located as described in the Site
Requirements section above and the flow cell is fitted in your
Mastersizer. If the flow cell is not fitted, refer to section G of the
Installation Guide (MAN 0100).
$
To connect your Accessory to a Mastersizer S or X:
.
Cut a suitable length of sample tubing and connect the sample out (bottom
connection) of the Dispersion Unit À to the bottom connection on the
flow cell Á. Pass the tube through the cover by squeezing the tube and fit-
ting it into the “keyhole” recess Â. Make sure the tube is not constricted.
CHAPTER 3
QS Small Volume Sample Dispersion Unit
Page 3.4
MAN 0161
