INTRODUCTION 18000 OPERATOR MANUAL
1-6
Published 12-05-17, Control # 032-23
CRANE WEIGHTS
Description
Weight
Pounds Kilograms
LIFTCRANE:
Upperworks and lowerworks complete, 4 swing drives, counterweight, 30 ft (9,1 m) live mast,
backhitch, 100 ft (30,5 m) No. 56 Mast, mast stops, 30 USt (27 t) hook and weight ball, boom stops
and load lines (includes self-erect and MAX-ER prep)
When equipped with fully rigged 120 ft (36,6 m) Boom No. 55-79A, standard upper boom point,
and 500 USt (454 t) block - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,478,930 670 831
When equipped with fully rigged 120 ft (36,6 m) Boom No. 55 or No. 55A, heavy duty upper boom
point, and 661 USt (600 t) block - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,513,720 686 611
UPPERWORKS REAR MACHINERY MODULE:
Rotating bed rear section with pin pullers, upperworks jacking system, 30 ft (9,1 m) live mast, mast
hoist with mast hoist line, Cummins QXF15 power plant, hydraulic reservoir (full), fuel tank
(1/2 full) and operators cab (drum 3 and catwalks removed) - - - - - - - - - - - - - - - - - 104,435 47 370
Upperworks jacking system removed - - - - - - - - - - - - - - - - - - - - - - - - - - - - 88,335 40 068
ADAPTER FRAME WITH CARBODY:
Rotating bed adapter frame with bearing turntable, 4 swing drives and carbody (includes MAX-ER
prep) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 95,900 43 499
MAST NO. 56 BUTT/TOP SHIPPING PACKAGE:
20 ft (6,1 m) mast butt, boom hoist drum with rope, boom hoist drum guide rollers, wire rope guide
sheave, mast stops, mast butt supports, boom equalizer, 20 ft (6,1 m) mast top with sheaves and
straps (includes MAX-ER prep) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 57,800 26 217
BOOM NO. 55 BUTT SHIPPING PACKAGE:
20 ft (6,1 m) boom butt, load hoist drum with rope, luffing drum with rope, rigging winch with rope,
cable reel, boom stops and boom hinge pin-pullers - - - - - - - - - - - - - - - - - - - - - 57,875 26 251
BOOM NO. 55 - 10 ft (3,0m) INSERT SHIPPING PACKAGE:
10 ft (3,0 m) insert, load hoist drum with rope and wire rope guide - - - - - - - - - - - - - - 35,960 16 311
CRAWLERS:
38 ft 9 in (11,8 m) crawler assembly (each) with drive and 60 in (1 524 mm) treads - - - - - - 88,255 40 031
COUNTERWEIGHT - UPPER:
Tray (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12,050 5 465
Counterweight (28 total) (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18,000 8 164
Rear catwalk with railings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,290 585
Total upperworks counterweight - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 528,000 239 496
COUNTERWEIGHT - LOWER:
Counterweight tray (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 28,000 12 700
Counterweight (each) (6 total - 3 front, 3 rear) - - - - - - - - - - - - - - - - - - - - - - - - - 44,000 19 958
Stairway (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 250 113
Total lowerworks counterweight - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 320,000 145 149
30 ft (9,1 m) LIVE MAST:
30 ft (9,1 m) mast with straps - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9,660 4 381
MACHINE OPTIONS:
Drum 3 assembly (whip line without rope) - - - - - - - - - - - - - - - - - - - - - - - - - - 5,250 2 381
Upperworks jacking system - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 14,700 6 667
Swing drive assemblies (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1,765 800
Rotating bed alignment pendants (each) - - - - - - - - - - - - - - - - - - - - - - - - - - 65 29
LOWERWORKS OPTIONS:
Carbody pedestals with pads (each) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 410 185
MAST NO. 56:
20 ft (6,1 m) mast butt with boom hoist drum with rope and guide sheave - - - - - - - - - - 33,905 15 379
20 ft (6,1 m) mast top with sheaves, wire rope guide and straps - - - - - - - - - - - - - - - 20,485 9 291
40 ft (12,2 m) insert with straps - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13,940 6 323
20 ft (6,1 m) insert with straps - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8,490 3 850
