18000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Hydraulic System Calibration
See Hydraulic System Calibration Procedures in this section.
Speed/Torque
See Function Speed/Torque Adjustment in this section.
Accessory System
The ACC system screen displays the following information:
• Drum 5 (mast hoist) control HANDLE command in
percent from neutral with + raise and - lower
• Accessory valve (ACC VLV) command in percent
• Drum 5 (mast hoist) pump (DM5 PMP) command in
percent from neutral with + raise and - lower
• Accessory system pressure (ACC PRES) in psi
• Drum 5 (mast hoist) pump pressure (DM5 PRES) in psi
• Drum 5 (mast hoist) drum speed (DM5 SPD) in RPM
• Accumulator system pressure (ACCUM PRES) in psi
• VALVES - displays binary number of system
components that are active in bank:
Bank 1:
1 = Jacking command
2 = Rotating frame command
4 = Mast raise switch and mast hoist control handle
command is OFF
8 = Mast lower switch and mast hoist control handle
command is OFF
16 = Boom hinge pins in switch
32 = Boom hinge pins out switch
64 = Mast pins in switch
128 = Mast pins out switch
256 = Cab tilt up
512 = Cab tilt down
1028 = Raise mast arms from stored position
2056 = Lower mast arms to stored position
4096 = MAX-ER cylinder
8192 = Rigging winch command
Wireless
The WIRELESS screen displays the following information:
• REMOTE TxID - where the link identification code is
entered and displayed. To enter a link identification
code, press select. The cursor (*) appears next to
remote TxID. Press select again to enter identification
code area. Scroll up or down to enter 0 to 9 and/or A to F,
press select to move through each four positions.
• SENSOR BANKS - where the four banks listed below
display information shown in table.
1. Link 1 information
2. Link 2 information
3. Link 3 information
4. Hand-held radio remote control information
5. Block Level control information
• LOAD LINK TRAFFIC where bank one is transmitter
identification and bank two property code (weight code
of link). The two banks work together and continuously
display information for each load link in immediate area.
PRESSURE SENDER CAL
CONTROL CAL
PUMP PRESSURE TEST
CHARGE PRESSURE
0%
0%
0%
0
0
0
0
0
0
DRUM 1 SPEED
DRUM 2 SPEED
DRUM 3 SPEED
DRUM 4 SPEED
25 %
50 %
25 %
25 %
DRUM 6 SPEED
TRAVEL SPEED
SWING SPEED
SWING TORQUE
25 %
75 %
25 %
60 %
HANDLE
ACC VLV
DM5 PMP
VALVES
+/-0 %
-0 %
+/-0 %
256
ACC PRES
DM5 PRES
DM5 SPD
ACCUM P
psi
psi
rpm
psi ACC
*REMOTE TxID
SENSOR BANKS:
LOAD LINK TRAFFIC
REMOTE TRAFFIC
0000
0
0
0
64
0
0
0 128 160
WIRELESS
Binary
Number
Information
1, 2, or 4 Disregard information displayed.
8 RF link suspect.
16 Configuration data corrupt.
32 Internal CPU error.
64 Sensor voltage out of range.
(Not used with block level sensor)
128 Sensor battery low.
