Manitowoc 18000 User Manual

Reference Only
SET-UP AND INSTALLATION 18000 OPERATOR MANUAL
4-44
Published 12-05-17, Control # 032-23
16
See
View L
See
View M
70 ft (21,3 m) for 100 ft (30,5 m) Mast
OR
110 ft (33,5 m) for 140 ft (42,7 m) Mast
FIGURE 4-27 continued
5
P1958a
P1958
View J
13
Stored
13
Inboard Side
14
15
P1241
P1241a
6
11
(stored)
View G
2 places
12
11
View H
2 places
View K
2 places
View L
2 places
View M
2 places
16
16
17
17
Item Description
3 Chain Sling, 4-Leg with Grab Hooks *
4 Lifting Lugs (4 each section)
5 Mast Butt
6 Mast Top
11 Retaining Pin with Snap Pin
12 Equalizer Fork
13 Pin with Safety Pin
14 Fixed Pin
15 Hooked Connector
16 Mast Insert – 20 ft (6,1 m)
17 Mast Insert – 40 ft (12,2 m)
1 Required for 100 ft (30,5 m) Mast
2 Required for 140 ft (42,7 m) Mast
* Same sling provided by Manitowoc for
crawler handling.
4-133
P1957
6
4
4
3
17
6
