LUBRICATION RT540E OPERATOR MANUAL
5-10 Published 01-15-2016, Control # 526-01
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Drive Train
13a
13b
Engine
Crankcase
Filter
Figure 5-3
EO-15W/40
Engine Oil
SAE 15W-40
T3 Engine -
6829003483
T4 Engine -
6829104182
17.5 l
(18.5 qt)
• Check level every 10
hours or daily
• Drain, fill and replace
filter every 500 hours
or 6 months
• Check level
through dipstick.
• Fill engine oil
through fill cap on
engine valve
cover.
14a
14b
Transmission,
Torque
Converter
a. Dipstick
b. Filter
Figure 5-3
HYDO
Hydraulic Oil
6829006444
23.6 l
(25 qt)
• Check level every 10
hours or daily
• Drain and refill every
1000 hours or 6
months
• Change transmission
filter after first 50 and
100 hours of service,
then every 500 hours
thereafter
Through fill pipe to
FULL mark on
dipstick
NOTE:
• Check fluid level with engine running at 750 rpm idle and the oil at 180 to 200 ° F (82 to 93° C). Do not attempt an oil level check
with cold oil. To bring the oil temperature to this range, it is necessary to either work the crane or stall the converter. Converter
stall should be accomplished by engaging shift lever in forward high range with the brakes applied and then accelerating the
engine to half or three-quarter throttle. Hold the stall until the required converter temperature is reached and stabilized.
Do not operate the converter at stall condition for longer than 30 seconds at one time. Shift to neutral for 15 seconds and repeat
the procedure until the desired temperature is reached. Excessive temperature, i.e, 250° F (120° C) maximum will cause damage
to transmission clutches, fluid, converter and seals.
• Drain and fill with the oil at 150 to 200° F (65 to 93° C).
• Transmission filters are located on the outside left hand frame in the area of the hydraulic oil cooler.
• To add fluid:
a. Fill to FULL mark on dipstick
b. Run engine at 750 rpm to prime torque converter and lines
c. Check oil level with engine running at 750 rpm and oil at 180 to 200° F (82 to 93° C (180 to 200° F). Add oil to bring
oil level to FULL mark on dipstick.
15
Engine Cooling
System and SCA
Levels
Figure 5-3
AFC 50/50
50/50 Blended
Fully
Formulated
Antifreeze
Coolant
6829101130
SCA
6829012858
28.4 l
(30 qt)
• Check coolant level
every 10 hours or
daily
• Check SCA levels
every 500 hours
• Check coolant for
contamination every
1000 hours
See Service Manual
16
Coolant Strainer
(Cab Heater)
Figure 5-3
--- ---
Change strainer screen
after first 100 hours and
every 2000 hours or 12
months intervals
thereafter.
Close shutoff valves.
Unscrew hex plug to
clean filter.
Reference Only
