INTRODUCTION RT540E OPERATOR MANUAL

1-4 Published 01-15-2016, Control # 526-01

SERIAL NUMBER LOCATION

Refer to Figure 1-2 for the locations of the crane serial

number.

Frame - Left Front

Inside Cab - Lower Right

8544

Manual Cover

FIGURE 1-2

Reference Only
