Manitowoc Grove RT540E User Manual

Published 01-15-2016, Control # 526-01 1-3
RT540E OPERATOR MANUAL INTRODUCTION
GROVE
1
Pump #2
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Gear
Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Output - @ 172.4 bar (2,500 psi) w/no load
Section 1. . . . . . . . . . . . .86.5 l/min (22.9 gpm)
Pump #3
Type . . . . . . . . . . . . . Gear with priority flow divider
Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Output - @ 199.9 bar (2,900 psi) w/no load
Section 1. . . . . . . . . . . . .57.2 l/min (15.1 gpm)
Hoists
Drum Dimensions
Diameter . . . . . . . . . . . . . . . 270 mm (10.63 in)
Length (Standard). . . . . . . . . 419 mm (16.5 in)
Cable
Diameter . . . . . . . . . . . . . . . . . . 16 mm (5/8 in)
Length-Main . . . . . . . . . . . . . . . .137 m (450 ft)
Length-Aux. . . . . . . . . . . . . . . . .137 m (450 ft)
Max. Permissible Line Pull
(6x36). . . . . . . . . . . . . . . . . . . . .52.4 kN (11,770 lb)
Max. Single Line Speed. . . .156.7 m/min (514 fpm)
Hoist Motor Displacement
Low . . . . . . . .107 cm
3
(6.53 in
3
) per revolution
High . . . . . . . .61 cm
3
(3,72 in
3
) per revolution
FIGURE 1-1
G7
80073532
1. LIFTING OF ENTIRE CRANE OR MAJOR CRANE ASSEMBLIES MUST BE ACCOMPLISHED BY
UTILIZING SPECIFIC FITTINGS INDICATED ON ABOVE CHART. USE OF FITTINGS FOR
PURPOSES OTHER THAN THOSE DESIGNATED ON CHART IS PROHIBITED.
FITTING CAPACITIES ARE MAXIMUM ALLOWABLE LOADS PER INDIVIDUAL FITTING.
2. RIGGING PERSONNEL SHALL BE RESPONSIBLE FOR PROPER SELECTION AND PLACEMENT
OF ALL SLINGS AND LOAD HANDLING DEVICES.
3. DIMENSIONS AND WEIGHTS SHOWN ARE FOR HEAVIEST CONFIGURATION AVAILABLE.
4. RIGGING PERSONNEL SHALL VERIFY DIMENSIONS AS REQUIRED FOR CLEARANCE.
5. EXTEND OUTRIGGER BEAMS 46 CM (18 IN) AND SLING AROUND BEAMS.
6. DO NOT USE PINTLE HOOKS OR CWT LUGS FOR LIFTING OR TIE DOWN OF ENTIRE CRANE.
TRANSPORTATION AND LIFTING DATA RT540E
TOTAL UNIT (WITH BOOM EXT)
REAR AXLE
L
C
A
1194.3 cm
(470.2 in)
B
328.2 cm
(129.2 in)
29185 kg
(64341 lb)
181.4 cm
(71.4)
CARRIER
131.6 cm
(58.1 in)
D
4271 kg
(9416 lb)
TURNTABLE (T/T)
470.7 cm
(185.3 in)
6118 kg
(13487 lb)
BOOM (W/O BOOM EXTENSION)
COUNTERWEIGHT (CWT)
76.5 cm
(30.1 in)
4305 kg
(9490 lb)
H
B
A
ROTATION
L
C
F
E
BOOM
PIVOT
L
C
TIE DOWN
NO./UNIT
LIFT
TOW
TOW
TIE DOWN
FITTING CAPACITY (TONS)
TOW
LIFT
TIE DOWN
FORE
&
AFT
SIDE DOWN
LIFT
LIFT
LIFT
CYL
T/T
BOOM
LIFT
LIFT
X
X
X
X
XX XX
X
X
X
X
TOTAL
UNIT
CARRIER
FITTINGS
A
B
C
D
E
F
G
H
J
4
4
2
2
2
2
2
2
–
12
7.9
2.3
3.4
3.4
2.2
9.4
N/A
SEE NOTE #5
82 25 35 7.1
LIFT
CWT
X
REAR AXLE
L
C
A
B
13109 kg
(28899 lb)
158.8 cm
(62.5 in)
B
A
G
C
J
(39.1 in)
99.3 cm
636 kg
(1403 lb)
8696
Reference Only
