Manitowoc Grove RT765E-2 - Page 176

BOOM RT765E-2 SERVICE MANUAL
4-26
Published 9-04-2014, Control # 422-08
Detail A
Detail B
6058
6058
5
6
4
2
2
3
1
7
Item Description
1
Boom Extension Base
Section
2 Adjusting Bolt
3 Upper Hanger
4 Main Hanger
5 Lower Support
6 Lock Hitch Pin
7 Adapter
6160
Item Description
1 Boom Extension Fly Section
2 Adjusting Bolt
3 Adjusting Bolts
4 Front Mount
5 Hanger
1
3
2
3
4
5
FIGURE 4-5 continued
Reference Only
