Manitowoc Grove RT765E-2

4-27
Published 9-04-2014, Control # 422-08
RT765E-2 SERVICE MANUAL BOOM
4
GROVE
Detail D
Item Description
1
Boom Extension Base
Section
2 Boom Extension Fly Section
3 Shock Wear Pad and Shim
4 Ramp Wear Pad and Shim
Detail C
2
4
3
1
1
2
3
4
5
6
7
8
4
Item Description
1 Boom Extension Base Section
2 Boom Extension Fly Section
3 Fly Attachment Pin and Hitch Pin
4 Adjusting Bolts
5 Pin Stowage Lug
6 Upper Support
7 Lower Mount Ramp
8 Wear Pad
FIGURE 4-5 continued
Reference Only
