Manitowoc Indigo Series User Manual

332 Part Number Preliminary 6/11
IB1090C/ICVD1195
Remote Air-Cooled Condensing Unit Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24-HOUR ICE PRODUCTION
OPERATING PRESSURES
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
9.3-10.7 10.1-11.7 11.1-12.7
.75-2.5
80/27 10.1-11.7 11.1-12.7 11.8-13.6
90/32 10.9-12.6 12.2-14.0 12.7-14.6
100/38 12.0-13.8 12.9-14.8 13.7-15.7
110/43 13.1-15.0 13.9-16.0 14.9-17.1
1
Times in minutes.
Air Temp.
Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
1000 930 860
80/27 930 860 810
90/32
870 790 760
100/38 800 750 710
110/43 740 700 660
1
Based on average ice slab weight of 7.5 - 8.5 lb.
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
-20 to 50/
-29 to 10
200-250 40-25 140-170 65-75
70/21 220-270 40-25 150-185 65-85
80/27 225-275 50-26 160-190 70-90
90/32 235-275 60-27 175-195 75-95
100/38 260-325 65-30 190-220 80-100
110/43 300-360 70-33 200-230 90-105
