SET-UP OPERATOR MANUAL NBT60XL
4-8 Published 11-01-2020 Control # 710-00
1Stow Pin
2 Jib Stowage Bracket
3 Hook Bracket
4 Boom
5 Jib Swing Pin
6 Right Side Attachment Pins
7 Left Side Attachment Pins
8Jib
9 Jib Retaining Pin
10 Alignment Jack
11 Jack Handle
12 A2B/RCL Connector
FIGURE 4-3
1
2
3
4
5
6
7
8
9
10
11
1
Stowed Position
for pin when jib is
erected.
12
9628
9629
9630
9631
Retaining Pin
Retaining Pin
and Spring Clip
9626
9627
Fo
r
Reference
Only
