Manitowoc QF0400 User Manual

230 Part Number 80-1230-9 10/10
GEARMOTOR RPMS
FILTER-DRIERS
The filter-driers used on Manitowoc ice machines are
manufactured to Manitowoc specifications.
The difference between a Manitowoc drier and an off-
the-shelf drier is in filtration. A Manitowoc drier has
dirt-retaining filtration, with fiberglass filters on both the
inlet and outlet ends. This is very important because
ice machines have a back-flushing action that takes
place during every Harvest cycle.
A Manitowoc filter-drier has high moisture and acid
removal capability.
The size of the filter-drier is important. The refrigerant
charge is critical. Using an improperly sized filter-drier
will cause the ice machine to be improperly charged
with refrigerant.
Listed below is the recommended OEM field
replacement drier:
Model 115V 230V
SN012 SN020 25.2 21.1
QF0400 8.3 8.9
QF0800 QC0700 15
QF2200 QF2300 11.6
SF0400 SN0450 SF0600 SN0650
SF0900 SN0950 SF0900C SN0950C
SF1200 SN1250 SF1200 SN1250
21
Model
Drier
Size
End
Connection
Size
SN012 SN020 QF0400
SF0400 SN0450
SF0600 SN0650 QF0800
QC0700 SF0900 SN0950
DML-032S 1/4"
SF0900C SN0950C DML-052S 1/4"
SF1200 SN1250
QF2200 QF2300
DML-053S 3/8"
Important
Driers are covered as a warranty part. The drier
must be replaced any time the system is opened for
repairs.
