60 Part Number 80-1230-9 10/10
QC0700/QF0800/QF2200/QF2300
Cleaning and Sanitizing Procedure
Step 1 Remove front and top cover and set the
toggle switch to the OFF position.
Step 2 Remove all ice from the bin/dispenser.
Step 3 Disconnect water supply line at float valve
quick disconnect by depressing stainless steel lever.
Step 4 Remove the top cover from the water
reservoir.
Step 5 Remove the water level probes from the top
cover and with wires attached, place the water level
probes (stand upright) inside the water reservoir.
Step 6 To start the cleaning procedure, move the
toggle switch to the ICE position. The gear motor will
start and the water dump valve will energize. Water
will flow through the water dump valve and down the
drain. The control board light for the dump valve, gear
motor, and speed will energize to indicate the ice
machine is starting the ice making sequence.
Step 7 Wait 45 seconds until the Dump Valve light
de-energizes and the Water Level Probe light
energizes. Add the proper amount of Manitowoc Ice
Machine Cleaner to the water reservoir.
Step 8 Reconnect the water supply line to the float
valve. When water contacts the water level probe, the
compressor will energize. The ice machine will freeze
and discharge the cleaning solution into the bin.
Continue the Freeze cycle for ten minutes to remove
all cleaning solution from the water reservoir.
Step 9 Discard all ice produced during the cleaning
process.
Step 10 Disconnect water supply line at float valve
quick disconnect by depressing stainless steel lever.
Model
Amount of Cleaner
Part Number 000000084
QF0800/QC0700 3 oz. (90 ml)
QF2200/QF2300 3 oz. (90 ml)
