84 Part Number 80-1230-9 10/10
SN012/SN020
Removal of Parts for Cleaning or Sanitizing
1. Turn off water supply to ice machine.
2. Place toggle switch in the clean position for 30
seconds to drain water from reservoir, then move
toggle switch to Off position.
3. Run dispenser to transfer all ice from the bin to a
container.
4. Disconnect electrical power to the ice machine.
5. Remove top cover.
A. Remove two screws.
B. Lift up on top cover to remove.
To Next Page
