Part Number 80-1230-9 10/10 281
Refrigeration Tubing Schematics
QF0400/QC0700/QF0800
Air & Water Cooled
EXPANSION
VALVE
EVAPORATOR
DRIER
CONDENSER
(AIR OR WATER)
COMPRESSOR
SV3082
RECEIVER
(QF0400 ONLY)
