Manitowoc QF0400 User Manual

26 Part Number 80-1230-9 10/10
Location of Traditional Remote Units and
Remote condensing units
The location selected for the Remote Units must meet
the following criteria. If any of these criteria are not
met, select another location.
• The air temperature must be at least -20°F
(-28.9°C) but must not exceed 120°F (49°C).
• The location must not allow exhaust fan heat and/
or grease to enter the condenser.
• The location must not obstruct airflow through or
around the condensing unit. Refer to the chart
below for clearance requirements.
• RFC Condensing Units ONLY - Interconnecting
wiring (115/60/1) is required between the ice
machine and condensing unit to energize the
contactor coil.
Traditional Remote/Condensing Unit Clearances
Traditional Remote
JC0495
Top/Bottom
Bottom clearance is 12" (31 cm)
Top clearance is 4’ (1.2 m)
Traditional Remote
JC0495
Sides
There is no minimum clearance
required, although 6" (15 cm) is
recommended for efficient operation
and servicing only.
Remote
Condensing Unit
RFC - Top/Sides
There is no minimum clearance
required, although 6" (15 cm) is
recommended for efficient operation
and servicing only.
Remote
Condensing Unit
RFC - Front/Back
4’ (1.2 m)
