Part Number 80-1230-9 10/10 35
• Maximum total amount of tubing is 100’ (30.5 M)
• Maximum height condenser or condensing unit
can be above ice machine is 35’ (10.7 M)
• Maximum distance condenser or condensing unit
can be below the ice machine 15’ (4.5 M)
• Condensing units only - Suction line oil trap is
required for any rise that is 20’ (6 M) or greater.
• Refer to Installation Use and Care Manual for
complete installation information.
Manitowoc remote systems are only approved
and warranted as a complete new package.
Warranty on the refrigeration system will be
void if a new ice machine head section is
connected to pre-existing (used) tubing or
remote condensers.
