Manitowoc QF0400 User Manual

Part Number 80-1230-9 10/10 73
Water Reservoir Cover Removal
QF2200/QF2300
1. Place the toggle switch in the OFF position, turn
off the water supply and disconnect electrical
power to the ice machine.
2. Remove water level probes.
3. Remove water float valve coil.
4. Depress coil and rotate 1/4 turn counterclockwise.
5. With coil wires attached, lift coil off enclosure
tube.
6. Remove top cover from float reservoir.
QF2200/QF2300 Shown
2
3, 4, 5
6
