47
Specifications
ENGLISH
n Audio Section
• Power amplifier
Rated output: 70 W + 70 W (1 kHz, 6 Ω, T.H.D. 10 %)
Effective maximum output: 55 W + 55 W (1 kHz, 6 Ω, T.H.D. 0.7 %)
Output connectors: 6 – 8 Ω
• Analog
Input sensitivity/Input impedance: AUX1: 100 mV/25 kΩ
AUX2/3: 200 mV/47 kΩ
n Video Section
• S-Video connectors
Output level and impedance: 1 Vp-p, 75 Ω
n Tuner section [FM] [AM]
Reception frequency range: 87.50 MHz – 108.00 MHz 522 kHz – 1611 kHz
Sensitivity (T.H.D. 3 %, IHF):
(S/N 30 dB):
6 dBμV
–
–
60 dBμV/m
FM stereo separation: 35 dB (1 kHz)
n Applicable Discs :
BD-Video discs : 12 cm 1 side 1 layer, 12 cm 1 side 2 layers
DVD-Video discs : 12 cm 1 side 1 layer, 12 cm 1 side 2 layers/
12 cm 2 sides 2 layers (1 side 1 layer)
8 cm 1 side 1 layer, 8 cm 1 side 2 layers/
8 cm 2 sides 2 layers (1 side 1 layer)
Compact Discs (CD-DA) : 12 cm / 8 cm discs
n General
Power supply: AC 230 V, 50 Hz
Power consumption: 67 W
0.5 W (Normal standby)
Maximum external dimensions: 280 (W) x 111 (H) x 302 (D) mm
Weight: 5 kg
n Remote Control Unit (RC001ER)
For purposes of improvement, specifications and design are subject to change without notice.
Specifications Index
v Numerics
4:3 LB (letterbox) ··········································36, 42
4:3 PS (pan scan) ··········································36, 42
24P Mode ···························································36
v A
A2DP ····························································11, 42
AAC ··················································15, 29, 30, 42
Accessories ·························································· 2
AM loop antenna ·················································· 2
Angle ··································································20
Aspect ratio ··················································36, 42
Audio ··································································36
Audio commentary ············································· 42
Auto preset ························································22
AVCHD ·························································14, 42
AVI ····················································15, 29, 30, 42
v B
BASS ··································································13
BD-J ·····························································18, 42
BD-LIVE ························································ 17, 42
BD-Live Internet Access ····································34
BD-Live Storage ·················································34
BD-Video ···························································· 14
Bit rate ································································42
Bluetooth ····························································11
Blu-ray Disc ························································42
Bonus View ··················································17, 42
v C
Cable
Audio cable ······················································ 10
Ethernet cable·················································· 27
HDMI cable ························································ 9
Pin-plug cable····················································· 8
Speaker cable ···················································· 8
Stereo mini plug cable ····································· 26
Video cable ························································ 9
CD-R/CD-RW ·················································· 4, 14
CD-RW ······························································· 14
Chapter ···························································4, 42
Characters ····················································29, 30
Color Depth ························································36
Connection
Antenna ··························································· 10
Cable TV ··························································· 10
iPod ·································································· 25
Network ··························································· 27
Portable audio player ········································ 26
Power cord ························································11
Satellite tuner ··················································· 10
Set-top box ······················································ 10
Speaker ······························································ 8
TV······································································· 9
USB memory device ·································· 25, 26
Wireless receiver (RX101) ·································11
Copyright protection ···········································41
CT ······································································· 24
Current time ·······················································14
v D
DBB ···································································· 13
Deep Color ····················································· 9, 42
DHCP ···························································27, 42
Direct mode ·······················································28
Display ····························································5, 36
Display’s brightness ···········································13
Dolby
Dolby Digital····················································· 42
Dolby Digital EX ··············································· 42
Dolby Digital Plus ············································· 42
Dolby Headphone ······································ 21, 42
Dolby TrueHD ··················································· 42
Dolby Virtual Speaker ································· 21, 42
Downmix ···························································· 42
DTS
DTS 96/24 ························································ 42
DTS Digital Surround ······································· 42
DTS-ES Discrete 6.1 ········································ 42
DTS-ES Matrix 6.1 ··········································· 42
DTS Express ···················································· 43
DTS-HD ···························································· 43
DTS-HD High Resolution Audio ······················· 43
DTS-HD Master Audio ····································· 43
DVD-R ································································14
DVD-R/DVD-RW ·················································14
DVD-RW ····························································· 14
DVD-Video ·························································· 14
DVI-D terminal ······················································ 9
Dynamic range ···················································43
Dynamic Range Control ·····································36
IndexTroubleshooting
