FRONT PANEL ASSY
Refer to
"DISASSEMBLY
1. FRONT PANEL ASSY"
and
"EXPLODED VIEW"
PCB H/P
(Ref. No. of EXPLODED VIEW : 9)
PCB USB
(Ref. No. of EXPLODED VIEW : 49)
PCB HDMI
(Ref. No. of EXPLODED VIEW : 12)
PCB FRONT
(Ref. No. of EXPLODED VIEW : 14)
RADIATOR ASSY
Refer to
"DISASSEMBLY
2. RADIATOR ASSY"
and
"EXPLODED VIEW"
PCB 7CH_AMP ASSY
(Ref. No. of EXPLODED VIEW : 24)
PCB GUIDE_L
(Ref. No. of EXPLODED VIEW : 18)
GUIDE CENTER FRONT PCB
(Ref. No. of EXPLODED VIEW : 15)
GUIDE CENTER PCB
(Ref. No. of EXPLODED VIEW : 16)
PCB HDMI ASSY
Refer to
"DISASSEMBLY
5. PCB HDMI ASSY"
and
"EXPLODED VIEW"
PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : 47)
REG ASSY
Refer to
"DISASSEMBLY
3. REG ASSY"
and
"EXPLODED VIEW"
PCB REG
(Ref. No. of EXPLODED VIEW : 40)
PCB REG_CNT
(Ref. No. of EXPLODED VIEW : 39)
PCB FFC_GUIDE
(Ref. No. of EXPLODED VIEW : 42)
AV ASSY
Refer to
"DISASSEMBLY
7. AV ASSY"
and
"EXPLODED VIEW"
PCB FRONT_CNT
(Ref. No. of EXPLODED VIEW : 43)
PCB SIDE_CNT
(Ref. No. of EXPLODED VIEW : 46)
PCB AUDIO_VIDEO ASSY
(Ref. No. of EXPLODED VIEW : 45)
TOP COVER
PCB RC5_MX
Refer to
"DISASSEMBLY
4. PCB RC5_MX"
and
"EXPLODED VIEW"
PCB RC5_MX
(Ref. No. of EXPLODED VIEW : 48)
POWER TRANS MAIN
Refer to
"DISASSEMBLY
6. POWER TRANS MAIN"
and
"EXPLODED VIEW"
POWER TRANS MAIN
(Ref. No. of EXPLODED VIEW : 31)
PCB SMPS
Refer to
"DISASSEMBLY
8. PCB SMPS"
and
"EXPLODED VIEW"
PCB SMPS
(Ref. No. of EXPLODED VIEW : 37)
PCB SPK
Refer to
"DISASSEMBLY
9. PCB SPK"
and
"EXPLODED VIEW"
PCB SPK
(Ref. No. of EXPLODED VIEW : 38)
DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
12
