3. REG ASSY
Proceeding : TOP COVER
→
RADIATOR ASSY
→
REG ASSY
(1) Disconnect the connector wires, then remove the screws.
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in REG ASSY.
Shooting direction: B
CP4603CP4602 CP4614CP4615
