2. RADIATOR ASSY
Proceeding : TOP COVER
→
RADIATOR ASSY
(1) Remove the screws.
(2) Remove the screws and Style pin.
View from the bottom
Shooting direction: D
Shooting direction: C
STYLE PIN : Loosen
15
