Marantz NR1504 /U1B - 5 CH_AMP PCB Assy Parts List

5CH_AMP
5CH
_
AMP PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D4800 00D9600197000 KDS160(UF) /USC K005016000010S 1
D4801 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4804 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4805 00D9600197000 KDS160(UF) /USC K005016000010S 1
D4806 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4807,4808 00D9600197000 KDS160(UF) /USC K005016000010S 2
D4811 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4812 00D9600197000 KDS160(UF) /USC K005016000010S 1
D4813 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4816 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4817 00D9600197000 KDS160(UF) /USC K005016000010S 1
D4818 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4821 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4822 00D9600197000 KDS160(UF) /USC K005016000010S 1
D4823 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4826 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
Q4800 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4801 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4803 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 1
Q4804 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4806,4807 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4809 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4810 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4811 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 1
Q4812 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4814 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4816,4817 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4819 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4820 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4821 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4823 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4825,4826 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4828 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4829 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4830 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4832 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4834,4835 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4837 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4838 00D2710314903 KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4839 00D2710318909 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4841 00D2730479909 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4843,4844 00D9600196205 KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4846 00D2730471907 KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
ZD4800 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4801,4802 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH K06003R344522S 2
ZD4803 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4804,4805 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH K06003R344522S 2
ZD4806 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4807,4808 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH K06003R344522S 2
ZD4809 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4810,4811 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH K06003R344522S 2
ZD4812 963202500300D ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4813,4814 963202500280D ZJ3.3B-0.5W/5MA-52MM SEMTECH K06003R344522S 2
RESISTOR GROUP
R4800 00D2412399912 1.8K-J,1/5W-52RE-AX C00001826P520S 1
R4801 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R4802 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R4803 963125003140S 5.6K-J,1W-R.REEL C060056265050S 1
R4804 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R4805 nsp 56K-J,1/16W-1608REEL C20005636M160S 1
R4806 963125003140S 5.6K-J,1W-R.REEL C060056265050S 1
R4807 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R4808 nsp JUMPER (0.6/52MM) L045084006040S 1
R4809 nsp 680K-J,1/5W-52RE-AX C00006846P520S 1
R4810 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R4811,4812 nsp C20001036M160S C20001036M160S 2
R4813 963125012630S 22-J,1W-5REEL C060022065050S 1
R4814 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R4815 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R4816,4817 nsp 22K-J,1/5W-52RE-AX C00002236P520S 2
R4818 nsp 220K-J,1/16W-1608REEL C20002246M160S 1
R4819 00D2412399954 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R4820 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4821,4822 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R4823 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R4825 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R4826 00D2412399954 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R4827 963121006300M 33K-J,1/5W-52RE-AX C00003336P520S 1
R4829,4830 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R4831 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R4832 nsp 220K-J,1/16W-1608REEL C20002246M160S 1
R4833 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R4834 963121006310M 470K-J,1/5W-52RE-AX C00004746P520S 1
R4835 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R4836,4837 963121006280M 220-J,1/5W-52RE-AX C00002216P520S 2
R4838 963125012630S 22-J,1W-5REEL C060022065050S 1
R4839 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
R4840 nsp 270-J,1/5W-52RE-AX C00002716P520S 1
R4841 nsp 1.2K-J,1W-5REEL C060012265050S 1
R4842 nsp 47-J,1W-R.REEL C060047065060S 1
R4843 00D2412399912 1.8K-J,1/5W-52RE-AX C00001826P520S 1
R4844 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R4845 963121006340M 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R4846 963125003140S 5.6K-J,1W-R.REEL C060056265050S 1
R4847 00D9630337908 33-J,1W-R.REEL C060033065050S 1
The symbols in the column "Remarks" indicate the following destinations.
U1 : North America model N1 : Europe model K1 : China model
BK : Black model SG : Silver gold model
