Marantz NR1504 /U1B - HDMI PCB Assy Parts List

FRONT
FRONT PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D4400,4401 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 2
D4409,4410 963209003510S CDS3C05HDMI1 CERADIODE ESD FOR HDMI 1608REEL K067030500010S 2
D4411 963209500020S CDS3C15GTA 1608REEL CERADIODE ESD B72500D0150A060 K067031500010S 1
D4412-4415 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 4
Q4400 00D9630226705 KTC1027Y,1W/TO92L-REEL J5021027Y0020S 1
Q4401 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4402 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4403 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q4404 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4405 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q4406 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4407 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q4408 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
IC4400 963232100400S UTC4580E SOP8 DUAL OP AMP J121458001010S 1 ＊
U4400 943172100150S 018BT021GINK 129*25*6.1 GREEN /AVR1913 K530180210010S 1
ZD4400 963202500330D ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
ZD4401 963202500350D ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 1
ZD4402 963202500340D ZJ15B-0.5W/5MA-52MM SEMTECH K06015R044522S 1
ZD4404-4406 963202500310D ZJ5.1B-0.5W/5MA-52MM SEMTECH K06005R144522S 3
RESISTOR GROUP
R4400,4401 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4402 00D9639006272 RSD-R1-1WJ-4.7 3*9 P=5MM SMALL R.REEL N113135647920S 1
R4403 nsp 0-J,1/16W-1608REEL U1 C20000006M160S 1
R4403 nsp 1.2-J,1/16W-1608REEL N1/K1 C2001R200M160S 1
R4405-4408 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 4
R4410 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4410 nsp 1.2-J,1/16W-1608REEL N1/K1 C2001R200M160S 1
R4411-4414 nsp 100-J,1/16W-1608REEL C20001016M160S 4
R4415,4416 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 2
R4418,4419 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R4420 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4421-4423 nsp 100-J,1/16W-1608REEL C20001016M160S 3
R4424 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4425 nsp 39K-J,1/16W-1608REEL C20003936M160S 1
R4426,4427 nsp 150-J,1/16W-1608REEL C20001516M160S 2
R4428 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4429 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4430 963121006280M 220-J,1/5W-52RE-AX C00002216P520S 1
R4431 nsp 39K-J,1/16W-1608REEL C20003936M160S 1
R4433 nsp 390-J,1/16W-1608REEL C20003916M160S 1
R4434 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4435-4437 nsp 100-J,1/16W-1608REEL C20001016M160S 3
R4439 nsp 300-J,1/16W-1608REEL C20003016M160S 1
R4441 nsp 39K-J,1/16W-1608REEL C20003936M160S 1
R4442,4443 nsp 10-J,1/16W-1608REEL C20001006M160S 2
R4444 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4445 nsp 47K-J,1/16W-1608REEL C20004736M160S 1
R4446 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4447 nsp 18K-J,1/16W-1608REEL C20001836M160S 1
R4449 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R4450 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4451 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4452 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R4453 nsp 560-J,1/16W-1608REEL C20005616M160S 1
R4454 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R4455 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4456 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4457,4458 nsp 0-J,1/16W-1608REEL C20000006M160S 2
R4459 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4460 nsp 0-J,1/16W-1608REEL C20000006M160S 1
CAPACIITORS GROUP
C4400,4401 00MOA10601620 10UF-M/16V,3*5-5RE SY D040100083050S 2
C4402,4403 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C4404 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4405,4406 nsp ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 2
C4407 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4408 963134012120S 100UF-M/63V,8*11.5 SHL SY D040101088050S 1
C4409 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4411 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4412-4415 nsp COG470PF-J/50V-1608REEL D010471167160S 4
C4416,4417 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 2
C4418 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4419 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C4420-4422 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 3
C4424 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 1
C4425-4427 nsp COG100PF-J/50V-1608REEL D010101167160S 3
C4428 nsp Y5V1UF-Z/50V-1608REEL
D011105597160S 1
C4430-4435 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 6
C4437 nsp COG82PF-J/50V-1608REEL D010820167160S 1
C4438 00D2544302974 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C4439 nsp COG100PF-J/50V-1608REEL D010101167160S 1
C4441 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4442 nsp 220UF-M/6.3V,8*5-5RE SRE SY D040221081070S 1
C4443,4444 nsp COG100PF-J/50V-1608REEL D010101167160S 2
C4446 00MOA10601620 10UF-M/16V,3*5-5RE SY D040100083050S 1
C4448 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4449 nsp 1UF-M/50V,3*5-5RE SY (Pb Free) D040010087090S 1
C4451,4452 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C4453,4454 nsp X7R0.01UF-K/50V-1608REEL D011103777160S 2
OTHER PARTS GROUP
BD4400,4401 nsp 0-J,1/16W-1608REEL C20000006M160S 2
BD4402 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 1
CN4400 nsp 300MM/8P 20010HS-08=CKM2002HR-08 WH1007#26 L002301082630S 1
The symbols in the column "Remarks" indicate the following destinations.
U1 : North America model N1 : Europe model K1 : China model
BK : Black model SG : Silver gold model
