Marantz NR1504 /U1B - HDMI PCB Assy Parts List (cont.)

HDMI
HDMI PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D1001 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D1004 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D1016 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D1030 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D1031 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 U1 K005041480230S 1
D1034 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1
D1035 963209010450S VCH4AG100R8MAT ESD PROTECTION 0.8PF 1005REEL K067040100080S 1
D1036 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D3007,3008 963204500220D LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 2
IC1000-1002 nsp EX3AV 3A VOL DC-DC CONVERTER QFN38 J048030030010S 3
IC1003 943239010400S NJM2845DL1-33 3.3V TO-252-3 LOW-DROP VOL REGULATOR J126284533010S 1
IC1004 943239100730S PST8448UR SYSTEM RESET SC-82AB MITSUMI J125844800010S 1
IC1006 nsp EX3AV 3A VOL DC-DC CONVERTER QFN38 J048030030010S 1
IC1007 943236012460S ADV7623 HDMI 1.4 TRANSCEIVER LQFP144 J040762305510S 1
IC1008 963248101920S
MX25L3206EM2I-12G 32M SERIAL FLASH SOP
8
・When update Firmware, please confirm a last version in SDI.
・Use the service board after u
p
datin
g
it.
U1/K1
8952150400020
1 ＊
IC1008 963248101930S
MX25L6406EM2I-12G 64M SERIAL FLASH SOP
8
・When update Firmware, please confirm a last version in SDI.
・Use the service board after u
p
datin
g
it.
N1 8952150400030 1 ＊
IC1011 00D2623077900 TC74VHCU04FT HEX INVERTER TSSOP14 J040740405580S 1
IC1012 963243101640S
EPM3032A-TC44 TQFP44 ALTER
A
・When update Firmware, please confirm a last version in SDI.
・Use the service board after u
p
datin
g
it.
8952150400040 1 ＊
IC1013 963239002150S SN74LVC244APWR TSSOP 20P/OCTAL BUFFER/DRIVER J040742440230S 1
IC1017-1019 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 3
IC1020 00D2623676903 TC74VHCT08AFTS1-TBB TSSOP14P QUAD 2-INPUT AND GATE J040740800350S 1
IC1021 00D2623444902 TC74VHC08FT CMOS 2-INPUT AND GATE TSSOP14 P-0.65 J040740800280S 1
IC1022 963262012150M R94EV1A 36KHZ STRAIGHT LEAD P=2.54MM U1 E940941003610S 1
IC1023 963243101650S
R5F56108VNFP 32BIT MICROCOMPUTER P-LQFP144 RENESA
S
・When update Firmware, please confirm a last version in SDI.
・Use the service board after u
p
datin
g
it.
8952150400010 1 ＊
IC1024 943239100720S R1EX24256BSAS0A 256Kbit SERIAL SOP8 RENESAS J000242565570S 1
IC1600 943239100830S SLI11131AFCAY8H FBGA289 HDMI TRANSMITTER J040111310080S 1
Q1000 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q1004-1007 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 4
Q1008,1009 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 2
Q1010 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1011 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1013 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1014 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q1015-1017 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 3
Q1019 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q1022-1029 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 8
Q1030,1031 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 2
Q1033 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
TR1000-1002 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 3
TR1003,1004 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 2
TR1005 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1
TR1006 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
TR1007 943216500050S RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
TR1008,1009 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 2
TR1010,1011 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 2
TR1012-1014 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 3
TR1015,1016 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2
TR1017 963219002180S 2SD2114KT146W SMT3 SOT23-REEL J5232114K0010S 1
TR1018 963212500030S ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 1
TR1019,1020 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2
TR1021 963212500030S ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 1
TR1022-1026 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 5
TR1027 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA U1 J520101411210S 1
TR1029 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1
TR1030 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
TR1031 963211500160D PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1
TR1032 963219004200S FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1
U1000 236810057606S ADV3002BSTZ 4-TO-1 HDMI SWITCH TQFP80 J040300205510S 1
U1001 943239100760S TC74VHC4051AFT TOSHIBA J040744051360S 1
U1004 943239100760S ADSP-21487KSWZ-2B SHARC PROCESSOR DSP LQFP176 J080214875550S 1
U1005 943246012690S W9864G6JH-6 1M*4BANKS*16BIT(64MB) TSOP54 J001986466010S 1
U1006 963248101950S
MX29LV160DBTI-70G 16M(2M*8/1M*16)3V TSOP4
8
・When update Firmware, please confirm a last version in SDI.
・Use the service board after u
p
datin
g
it.
8952150400050 1 ＊
U1201 nsp AD8195 HDMI/DVI BUFFER EQ LFCSP40 J040819505510S 1
U2203 23681014050AS PCM9211 TRANSCEIVER LQFP48 J046921100010S 1
U2404 nsp PCM1690 HTSSOP48 J042169000010S 1
U2602 23681011260AS DM860A NETWORKED MEDIA PROCESSOR LFBGA320 J080860A05510S 1
U2603 963248101910S
H27U1G8F2BTR 1Gbit NAND FLASH TSOP48 TS
I
・When update Firmware, please confirm a last version in SDI.
・Use the service board after u
p
datin
g
it.
8952160400030 1 ＊ Ver.2
U2604,2605 963246100740D A3V56S30FTP-G6 256Mb SDRAM TSOP54 J001030563060S 2
U2802 nsp LAN8720A ETHERNET TRANSCEIVER QFN24 SMSC J127872005510S 1
U2805 nsp MFI337S3959 COPROCESSOR(IPOD) DENON SAGUB J044337395910S 1
U2806 nsp NCP380HMU15AATBG UDFN6 J127380150010S 1
RESISTOR GROUP
R1000 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1001 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R1002 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R1003 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1005 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 1
R1012 nsp 150K-D,1/16W-1608REEL C20001541M160S 1
R1013 nsp 47K-D,1/16W-1608REEL C20004731M160S 1
R1014 nsp 150K-D,1/16W-1608REEL C20001541M160S 1
R1015 nsp 120K-D,1/16W-1608REEL C20001241M160S 1
R1016 nsp 150K-D,1/16W-1608REEL C20001541M160S 1
R1017 nsp 470K-D,1/16W-1608REEL C20004741M160S 1
The symbols in the column "Remarks" indicate the following destinations.
U1 : North America model N1 : Europe model K1 : China model
BK : Black model SG : Silver gold model
