Marantz NR1504 /U1B - HDMI PCB Assy Parts List (cont.)

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R2817 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R2819 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R2820 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2822-2825 nsp 10K-J,1/16W-1005REEL C20001036M111S 4
R2826 nsp 1.5K-F,1/16W-1005REEL C20001524M100S 1
R2827 nsp 1.5K-J,1/16W-1005REEL C20001526M101S 1
R2828 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
R2829,2830 nsp 49.9-F,1/16W-1608REEL C20049R94M161S 2
R2831 nsp 8.2K-F,1/16W-1005REEL C20008224M101S 1
R2832,2833 nsp 49.9-F,1/16W-1608REEL C20049R94M161S 2
R2834 nsp 3.9K-F,1/16W-1005REEL C20003924M100S 1
R2849-2851 nsp 0-J,1/16W-1005REEL C20000006M101S 3
R2856 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2859 nsp 0-J,1/16W-1005REEL C20000006M101S 1
R2863 nsp 100-J,1/16W-1005REEL C20001016M101S 1
R2864,2865 nsp 4.7K-J,1/16W-1005REEL C20004726M101S 2
R3046 nsp 33-J,1/16W-1005REEL C20003306M101S 1
R3106 nsp 10K-J,1/16W-1005REEL C20001036M111S 1
CAPACIITORS GROUP
C1000-1002 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 3
C1009-1011 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 3
C1012-1014 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 3
C1015-1017 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 3
C1018-1023 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 6
C1024 nsp COG)10PF-J/50V-1608REEL D010100167161S 1
C1025,1026 nsp COG15PF-J/50V-1608REEL D010150167160S 2
C1033-1040 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 8
C1041,1042 nsp X7R)1UF-K/10V-1608REEL D011105772161S 2
C1069 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1072 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1081 nsp X7R0.015UF-K/50V-1608REEL D011153777160S 1
C1090 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1091 00D9630325402 470UF-MVG/6.3V,8.3*9.0*10 REEL (Z8158) SY D050471081200S 1
C1099 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1101 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1109 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1113 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1130 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1163-1169 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 7
C1170 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1171 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1172 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1173 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1174 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1176 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1181 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1188-1192 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 5
C1195 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1201-1209 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 9
C1211 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1224 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1229 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1230 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1231,1232 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 2
C1233 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1234 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1236 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1237 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1238 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1239 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1240 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1241 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1242 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1243 nsp COG)12PF-J/50V-1005REEL D011120167101S 1
C1244,1245 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1246,1247 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 2
C1248,1249 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1250 nsp COG)15PF-J/50V-1005REEL D011150167101S 1
C1251 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1252-1254 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 3
C1255,1256 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1257 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1258,1259 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 2
C1260-1262 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 3
C1263,1264 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 2
C1265,1266 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1267,1268 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 2
C1269,1270 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1271,1272 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 2
C1273 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1274 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1276 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1277 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1279 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1280 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1281 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1282,1283 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1284 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1285 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1286 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1287 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1288,1289 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 2
C1290,1291 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1292,1293 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 2
C1294 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1295 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1296 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1297 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1300 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1302 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1303,1304 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 2
C1306 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1307 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1310 nsp X7R)0.01UF-K/50V-1005REEL D011103777101S 1
C1311 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
13
