Marantz NR1504 /U1B - 6. Power Trans Main Disassembly (cont.)

(3) Remove the Style pin.
(4) Remove the screws.
NOTE :
It will separate and TRANS will fall from SET, if screws is removed.
Shooting direction: D
STYLE PIN : Loosen
CP4401
View from the bottom
21
