Marantz PM5004 User Manual

9
Getting started
Basic connections Troubleshooting Specifi cations IndexAdvanced connections Advanced operation Explanation terms
ENGLISH
Basic operation
1
Use either <INPUT SELECTOR> or [INPUT d,f] to
select an input source you want for playback.
The input indicator for the selected source lights.
GSelectable sourcesH
PHONO TUNER CD AUX/DVD RECORDER-1
RECORDER-2
• You can also select an input source by pressing the Input selector
buttons of the remote control.
• The input source you select is stored in memory even after you turn
off power, and the same source is selected when power is turned
on again.
2
Press <SPEAKERS A/B> to select the speaker system
to be used for playback.
The indicator for the selected speaker system lights.
3
Start playing back the source.
4
Adjust the VOLUME to the desired level.
n Adjusting the tone
• <BASS> Adjusts the bass sound.
• <TREBLE> Adjusts the treble sound.
• <BALANCE> Adjusts the left and right output balance.
Direct playback using a source audio
component
Since the audio signals bypass the tone control circuits (BASS/
TREBLE/BALANCE), the music reproduction is more faithful to the
original sound.
Press SOURCE DIRECT.
The SOURCE DIRECT indicator lights.
To adjust the tone, turn off SOURCE DIRECT.
Playback using the LOUDNESS function
This feature performs playback after compensating for insuffi cient
bass and treble response at low volume levels to reproduce a more
balanced sound.
Press <LOUDNESS> .
The LOUDNESS indicator lights.
Muting sound
This function mutes the sound by stopping audio output.
Press [MUTE] .
The MUTE indicator lights.
• To cancel the mute operation, press the button again.
You can also cancel the mute operation by operating VOLUME of
the remote control.
Starting playback Using headphone set
Plug headphones into PHONES jack.
• To listen with headphones, turn speaker output OFF.
n Adjusting the volume
Adjust the VOLUME to the desired level.
NOTE
To prevent hearing loss, do not raise the volume level excessively
when using headphones.
Starting Recording
1
Use either <INPUT SELECTOR> or [INPUT d,f] to
select the input source you want to record.
2
Set the recorder to recording mode.
3
Start playback of the source you want to record.
• Recording will start in sync with the playback operation of the
source.
1.PM5004NENG校了.inddSec1:91.PM5004NENG校了.inddSec1:9 2010/05/2020:24:462010/05/2020:24:46

Marantz PM5004 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	10 - 50000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	85 dB
Total Harmonic Distortion (THD)	0.0001 %
Dynamic power per channel (4 Ohm)	60 W
Dynamic power per channel (8 Ohm)	45 W
RMS power output per channel (4 Ohm)	55 W
RMS power output per channel (8 Ohm)	40 W
Bridge-mode power output per channel (4 Ohm)	80 W
AC (power) in	Yes
Audio (L/R) in	6
Audio (L/R) out	2
Headphone outputs	1
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Connectivity technology	Wired
Power consumption (standby)	0.4 W
Power consumption (typical)	110 W

Weight and Dimensions

Depth	369 mm
Width	440 mm
Height	105 mm
Weight	6700 g
