Marantz PM5004 User Manual

1
Getting started
Basic connections Basic operation Troubleshooting Specifi cations IndexAdvanced connections Advanced operation Explanation terms
ENGLISH
Thank you for purchasing this MARANTZ product. To ensure properoperation, please read this owner’s manual carefully before using the
product.
After reading the manual, be sure to keep it for future reference.
Getting started
Getting started
Contents
Getting started ·······································································1
Accessories ····················································································1
About this manual ········································································1
Main features ·················································································2
Cautions on handling ····································································3
About the remote control·····························································3
Inserting the batteries···································································3
Operating range of the remote control ········································3
Part names and functions·····························································4
Front panel ····················································································4
Rear panel ·····················································································4
Remote control ·············································································5
Basic connections··································································6
Preparations ··················································································6
Connecting cables ········································································6
Connecting the audio equipment ················································ 6
Connecting the speakers ······························································ 6
Connecting the speakers cables ···················································6
Speaker connections ····································································7
Connecting players ·······································································7
Connecting recorders ···································································7
Connecting the power cord··························································8
Basic operation ·······································································8
Before use ······················································································8
Turning the power on ···································································8
Turning the power standby ···························································8
Turning the power off ···································································8
Starting playback ··········································································9
Direct playback using a source audio component ························9
Playback using the LOUDNESS function ······································9
Muting sound················································································9
Using headphone set ···································································· 9
Starting Recording ········································································ 9
Advanced connections······················································10
Connecting the remote control jacks ········································ 10
Advanced operations·························································11
Remote control settings ····························································· 11
Setting remote control codes ····················································11
Setting remote control codes for the remote control ·················11
Setting remote control codes for this unit ··································11
Troubleshooting···································································12
Specifi cations ········································································13
Explanation terms ·······························································14
Index ··························································································14
Accessories
Check that the following parts are supplied with the product.
q Owner’s manual ......................................................................1
w Power cord (Cord length: Approx. 1.8 m) .................................1
e Remote control (RC003PM) .................................................... 1
r R03/AAA batteries ................................................................... 2
w
e
About this manual
n Operation buttons
The operations described in this manual are based mainly on
remote control operation.
n Symbols
v
This symbol indicates a reference page on which
related information is described.
This symbol indicates a supplementary information
and tips for operations.
NOTE
This symbol indicates points to remember operations
or function limitations.
n Illustrations
Note that the illustrations in these instructions are for explanation
purposes and may differ from the actual unit.
1.PM5004NENG校了.inddSec1:11.PM5004NENG校了.inddSec1:1 2010/05/2020:24:442010/05/2020:24:44

Marantz PM5004 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	10 - 50000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	85 dB
Total Harmonic Distortion (THD)	0.0001 %
Dynamic power per channel (4 Ohm)	60 W
Dynamic power per channel (8 Ohm)	45 W
RMS power output per channel (4 Ohm)	55 W
RMS power output per channel (8 Ohm)	40 W
Bridge-mode power output per channel (4 Ohm)	80 W
AC (power) in	Yes
Audio (L/R) in	6
Audio (L/R) out	2
Headphone outputs	1
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Connectivity technology	Wired
Power consumption (standby)	0.4 W
Power consumption (typical)	110 W

Weight and Dimensions

Depth	369 mm
Width	440 mm
Height	105 mm
Weight	6700 g
