Marantz PM5004 User Manual

14
ENGLISH
Index
v A
Adjusting the tone ················································9
Adjusting the volume ··········································· 9
v B
BALANCE ························································· 4, 8
BASS ································································ 4, 8
Batteries ······························································· 3
v C
Connection
Connecting cables ············································· 6
Connecting players ············································ 7
Connecting recorders ········································ 7
Connecting the speakers ······························· 6, 7
v I
INPUT SELECTOR ············································ 4, 8
v M
Mute ································································· 4, 8
v P
Power cord ···························································8
Protection circuit ············································ 6, 14
v R
Remote control ···································· 3, 5, 10, 11
v S
SOURCE DIRECT ············································· 4, 8
Speaker cables ················································· 6, 7
Stereo pin-plug cable ············································ 6
v T
TREBLE ···························································· 4, 8
v V
VOLUME ·························································· 4, 8
P
Protection Circuit
This is a function to prevent damage to components
within the power supply when an abnormality such
as an overload or excess voltage occurs for any
reason.
In this unit, the power indicator blinks and the unit
enters standby mode when an abnormality occurs.
S
Speaker impedance
This is certain-rated resistance of the speaker set
to an alternating current and expressed in ohms.
The smaller the impedance, the greater the output.
However, load on the amplifi er is increased. Use
speakers whose impedance is supported by this
unit.
Explanation terms
1.PM5004NENG校了.inddSec1:141.PM5004NENG校了.inddSec1:14 2010/05/2020:24:472010/05/2020:24:47

Marantz PM5004 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	10 - 50000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	85 dB
Total Harmonic Distortion (THD)	0.0001 %
Dynamic power per channel (4 Ohm)	60 W
Dynamic power per channel (8 Ohm)	45 W
RMS power output per channel (4 Ohm)	55 W
RMS power output per channel (8 Ohm)	40 W
Bridge-mode power output per channel (4 Ohm)	80 W
AC (power) in	Yes
Audio (L/R) in	6
Audio (L/R) out	2
Headphone outputs	1
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Connectivity technology	Wired
Power consumption (standby)	0.4 W
Power consumption (typical)	110 W

Weight and Dimensions

Depth	369 mm
Width	440 mm
Height	105 mm
Weight	6700 g
