Marantz PMD620MKII - Remote

41
Remote
The PMD620MK II allows you to use an optional remote controller
RC600PMD. (sold separately). The RC600PMD is designed
for microphone interviews. It attaches to your microphone. The
remote’s five feet cord with a four contact mini plug, plugs into
the PMD620MK
II . The RC600PMD does not require any menu
changes for use.
REMOTE DC IN
PHONES LINE OUT
REMOTE
RC600PMD
The RC600PMD includes:
a
b
c
d
a An indicator light:
• (green)litandsteadyduringstandbyorstop
• (red)litandsteadywhilerecording
• (flashingred)duringRec-Pausemode
• (orange) flashes for 1/2 second when an over peak level
signal is input during Record or Rec-Pause mode, then it
goes back to red.
b push to pause recording
c push to start/resume recording and to manually increment files
d Invalid
