DISASSEMBLY
• Disassembleinorderofthearrowinthefollowinggure.
• Inthecaseofthere-assembling,assembleitinorderofthereverseofthefollowingow.
In the case of the re-assembling, observe "attention of assembling".
If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PCB FRONT HDMI ASSY
(Ref. No. of EXPLODED VIEW : P2)
PCB USB ASSY
(Ref. No. of EXPLODED VIEW : P3)
PCB FRONT ASSY
(Ref. No. of EXPLODED VIEW : P4)
PCB H/P ASSY
(Ref. No. of EXPLODED VIEW : P1)
RADIATOR ASSY
Refer to "DISASSEMBLY
9. RADIATOR ASSY"
and "EXPLODED VIEW"
PCB AMP ASSY
(Ref. No. of EXPLODED VIEW : P8)
PCB TOP_GUIDE
(Ref. No. of EXPLODED VIEW : P9)
POWER TRANS MAIN
Refer to "DISASSEMBLY
4. POWER TRANS MAIN"
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : P31)
PCB MAIN ASSY
Refer to "DISASSEMBLY
7. PCB MAIN ASSY"
and "EXPLODED VIEW"
PCB MAIN ASSY
(Ref. No. of EXPLODED VIEW : P12)
PCB INPUT ASSY
(Ref. No. of EXPLODED VIEW : P13)
TOP COVER
PCB HDMI
Refer to "DISASSEMBLY
3. PCB HDMI"
and "EXPLODED VIEW"
PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : P16)
PCB MX PORT/PCB RS232C
Refer to "DISASSEMBLY
2. PCB MX PORT/PCB RS232C"
and "EXPLODED VIEW"
PCB RS232C ASSY
(Ref. No. of EXPLODED VIEW : P15)
PCB MX PORT ASSY
(Ref. No. of EXPLODED VIEW : P17)
PCB HDAM ASSY
(Ref. No. of EXPLODED VIEW : P7)
PCB HDAM CNT ASSY
(Ref. No. of EXPLODED VIEW : P6)
PCB VIDEO
Refer to "DISASSEMBLY
5. PCB VIDEO"
and "EXPLODED VIEW"
PCB VIDEO ASSY
(Ref. No. of EXPLODED VIEW : P19)
PCB PREOUT
Refer to "DISASSEMBLY
6. PCB PREOUT"
and "EXPLODED VIEW"
PCB PREOUT ASSY
(Ref. No. of EXPLODED VIEW : P20)
PCB FRONT CNT ASSY
(Ref. No. of EXPLODED VIEW : P14)
BACK CHASSIS
PCB SMPS
Refer to "DISASSEMBLY
8. PCB SMPS"
and "EXPLODED VIEW"
PCB SMPS ASSY
(Ref. No. of EXPLODED VIEW : P18)
11
